📘 MASTER–SLAVE TRADER API DOCUMENTATION

This documentation contains full technical details of all Master and Slave Trader APIs including schemas, validation rules, field descriptions, and examples.

# 🔐 Global Rule — IP Restriction Behavior

All API routes first verify the client's IP:

  • restricted_ip fetched from Company Info

Restriction Logic Used in Every API

# Check if the user's IP is allowed to access the system:
    RETURN:
    {
      "success": True,
      "message": "This IP (X.X.X.X) is not allowed to access this site"
    }

Important:

✔ If restricted_ip is empty, ALL IPs are allowed.

✔ If restricted_ip is set, ONLY that IP is allowed.

✔ Even failed operations return { success: true } when blocked.

====================

# 👨‍✈️ MASTER TRADER API

====================

## 1️⃣ Get All Master Traders

Endpoint

GET /api/get-all-master-traders

Description

Fetches a full list of all master traders.

Headers Required

None (only IP validation)

Response Format

{
  "success": true,
  "data": [...]
}

Response Example

{
  "success": true,
  "data": [
    {
      "trade_id": 1,
      "create_time": "2025-10-13T17:02:28",
      "update_time": "2025-11-25T16:39:29",
      "last_login_time": "2025-11-28 15:58:20.440001",
      "name": "John Deo",
      "email": "wovexo8700@eoilup.com",
      "mobile_number": "5986547578",
      "password": "123",
      "no_of_slave": 15,
      "status": 1,
      "mt_path": 1,
      "mt5_login": "{\"server\":\"octafx1234\",\"account\":\"456987\",\"password\":\"123\"}",
      "login_status": "success",
      "account_no": 456987
    }
  ]
}

## 2️⃣ Add a New Master Trader

Endpoint

POST /api/add-master-trader

Description

Adds a new master trader.

Email must be unique.

Request Schema

{
  "name": "string",
  "email": "string",
  "password": "string",
  "mobile_number": "string",
  "no_of_slave": "integer",
  "status": "integer (1 or 0)",
  "start_date": "YYYY-MM-DD",
  "end_date": "YYYY-MM-DD",
  "mt_path": "integer (optional)"
}

Field Descriptions

FieldTypeRequiredDescription
namestringYesFull name of master trader
emailstringYesMust be unique
passwordstringYesPassword stored as plain text
mobile_numberstringYesPhone number
no_of_slaveintYesNumber of allowed slave accounts
statusintYes1=active, 0=inactive
start_datestringNoSubscription start date
end_datestringNoSubscription end date
mt_pathintNoMT5 path ID

Example Request

{
  "name": "John Deo",
  "email": "johndeo@test.com",
  "password": "123456",
  "mobile_number": "9873214568",
  "no_of_slave": 5,
  "status": 1,
  "start_date": "2025-01-01",
  "end_date": "2025-12-31"
}

Success Response

{
  "success": true,
  "message": "Master trader added successfully."
}

Error Response

{
  "success": false,
  "message": "Email already exists OR failed to add."
}

## 3️⃣ Update Master Trader

Endpoint

POST /api/edit-master-trader/{trade_id}

Description

Updates any field of master trader.

All fields optional.

Request Schema

{
  "name": "string (optional)",
  "email": "string (optional)",
  "password": "string (optional)",
  "mobile_number": "string (optional)",
  "no_of_slave": "integer (optional)",
  "status": "integer (optional)",
  "start_date": "YYYY-MM-DD (optional)",
  "end_date": "YYYY-MM-DD (optional)",
  "mt_path": "integer (optional)"
}

Example

{
  "name": "John Deo",
  "email": "johndeo@test.com",
  "password": "123",
  "mobile_number": "9873214568",
  "no_of_slave": 15,
  "status": 1
}

Success Response

{
  "success": true,
  "message": "Master trader updated successfully."
}

## 4️⃣ Delete Master Trader

Endpoint

POST /api/delete-master-trader/{trade_id}

Description

Deletes a master trader using ID.

Success Response

{
  "success": true,
  "message": "Master trader ID 6 deleted successfully."
}

## 5️⃣ Update Master Trader MT5 Login

Endpoint

POST /api/update-master-mt5-login/{trade_id}

Description

Updates MT5 login and clears trading-related fields.

Also checks if account number is already used by any master or slave.

Request Schema

{
  "server": "string",
  "password": "string",
  "account": "string or number"
}

Example

{
  "server": "octafx1234",
  "password": "123home",
  "account": "15975356"
}

Success Response

{
  "success": true,
  "message": "Master MT5 login updated successfully."
}

Duplicate Account Error

{
  "success": false,
  "message": "Account number already exists in master or slave trader."
}

=================

# 👨‍💻 SLAVE TRADER API

=================

## 6️⃣ Get All Slave Traders

Endpoint

GET /api/get-all-slave-traders

Description

Fetches all slave traders.

Response Example

{
  "success": true,
  "data": [
    {
      "slave_id": 1,
      "name": "Slave User",
      "email": "slave@example.com",
      "mobile_number": "5698458965",
      "status": 1,
      "master_id": 1,
      "master_email": "wovexo8700@eoilup.com",
      "start_date": "2025-01-01",
      "end_date": "2025-12-31",
      "mt5_login": "{\"server\":\"112233\", \"account\":\"123789\", \"password\":\"123456\"}",
      "account_no": 123789
    }
  ]
}

## 7️⃣ Add a New Slave Trader

Endpoint

POST /api/add-slave-trader

Description

Adds a new slave trader under a master trader.

Master ID + Master Email must match an existing master (validated by master_exists()).

Request Schema

{
  "name": "string",
  "email": "string",
  "mobile_number": "string",
  "status": 1,
  "start_date": "YYYY-MM-DD",
  "end_date": "YYYY-MM-DD",
  "master_id": 6,
  "master_email": "string",
  "mt_path": 1
}

Field Descriptions

FieldTypeRequiredDescription
namestringYesFull name of the slave trader.
emailstringYesEmail of the slave trader. Must be unique across master + slave users.
mobile_numberstringYesPhone number of the slave trader.
statusintYesStatus of the slave: 1 = active, 0 = inactive.
start_datestringNoSubscription start date in YYYY-MM-DD format.
end_datestringNoSubscription end date in YYYY-MM-DD format.
master_idintYesID of the master trader under whom this slave is created. Must exist in master table.
master_emailstringYesEmail of the same master trader. Must match the master_id.
mt_pathintNoOptional MT5 terminal/path identifier for this slave.

Example Request

{
  "name": "Slave User",
  "email": "slavetest@test.com",
  "mobile_number": "5824568569",
  "status": 1,
  "start_date": "2025-01-01",
  "end_date": "2025-12-31",
  "master_id": 6,
  "master_email": "test@test.com"
}

Success Response

{
  "success": true,
  "message": "Slave trader added successfully."
}

Validation Error (Invalid Master)

{
  "success": false,
  "message": "Invalid master credentials (master_id and email do not match)."
}

## 8️⃣ Update Slave Trader

Endpoint

POST /api/edit-slave-trader/{slave_id}

Example

{
  "name": "Slave User",
  "email": "slavetest@test.com",
  "mobile_number": "5824568569",
  "status": 0,
  "start_date": "2025-11-01",
  "end_date": "2026-02-01"
}

Success Response

{
  "success": true,
  "message": "Slave trader updated successfully."
}

## 9️⃣ Delete Slave Trader

Endpoint

POST /api/delete-slave-trader/{slave_id}

Success Response

{
  "success": true,
  "message": "Slave trader ID 4 deleted successfully."
}

## 🔟 Update Slave Trader MT5 Login

Endpoint

POST /api/update-slave-mt5-login/{slave_id}

Request Example

{
  "server": "Exness-Trial9",
  "password": "123test",
  "account": "5858694"
}

Success Response

{
  "success": true,
  "message": "Slave MT5 login updated successfully."
}

Account Already Exists

{
  "success": false,
  "message": "Account number already exists in master or slave trader."
}

## 1️⃣1️⃣ Update Slave Inputs

Endpoint

POST /api/update-slave-inputs/{slave_id}

Description

Updates trade input configuration for a specific Slave Trader.

Stores values under input column as JSON.

Request Body Schema

{
  "magic": 12345,
  "lot_type": "fix | same_master | multiply_from_master | auto_lot",
  "fix_size": 0.5,
  "multiplier": 2.0,
  "trade_type": "as_it_is | opposite"
}

Field Descriptions

FieldTypeDescription
magicintMagic number identifier used in MT5 trades.
lot_typeenumDefines lot behaviour.🔹 fix → use fixed lot🔹 same_master → same lot as master🔹 multiply_from_master → lot = master * multiplier🔹 auto_lot → dynamic allocation
fix_sizefloatFixed lot size.
multiplierfloatUsed for Multiplier value.
trade_typeenum🔹 as_it_is → copy trade direction🔹 opposite → take reverse direction

Example Request

{
  "magic": 12345,
  "lot_type": "multiply_from_master",
  "fix_size": 0.01,
  "multiplier": 2,
  "trade_type": "as_it_is"
}

Success Response

{
  "success": true,
  "message": "Slave Inputs updated successfully."
}

Failure Response

{
  "success": false,
  "message": "Slave Inputs update failed"
}

## 1️⃣2️⃣ Update Trade Symbols for Master

Endpoint

POST /api/update-trade-symbol/{trade_id}

Description

Assigns tradable symbols to a master trader.

Moves symbols from all_symbol → trade_symbol, invalid symbols ignored.

Request Body Schema

{
  "trade_symbol": ["XAUUSD", "BTCUSD"]
}

Validation Behavior

ConditionResult
Symbol exists inside all_symbolAdded to trade_symbol
Symbol not present in allowed listReturned under "invalid_ignored"
No valid symbols providedRequest fails

Example Request

{
  "trade_symbol": ["EURUSD", "GBPUSD", "FAKE"]
}

Success Response

{
  "success": true,
  "message": "Trade symbols updated",
  "trade_symbol_added": ["EURUSD", "GBPUSD"],
  "invalid_ignored": ["FAKE"],
  "updated_all_symbol": ["XAUUSD", "BTCUSD"]
}

No valid symbol case

{
  "success": false,
  "message": "No valid symbols found inside all_symbol!",
  "invalid_symbols": ["FAKE"]
}

## 1️⃣3️⃣ Update Magic Numbers (Master Trader)

Endpoint

POST /api/update-magic-no/{trade_id}

Description

Updates Master magic numbers list and replaces previous values.

Request Body Schema

{
  "magic_no": [1234, 5678, 9999]
}

Success Response

{
  "success": true,
  "message": "Magic Numbers updated successfully",
  "magic_no": [1234, 5678, 9999]
}

Failure Example

{
  "success": false,
  "message": "Failed to update magic numbers"
}

## 1️⃣4️⃣ Re-login All Slave Traders

Endpoint

POST /api/relogin-slave-all

Description

Clears all failed login status for slave traders and resets them for relogin.

Success Response

{
  "success": true,
  "message": "Failed slave traders cleared successfully.",
  "failed_before_clear": 7
}

## 1️⃣5️⃣ Re-login All Master Traders

Endpoint

POST /api/relogin-master-all

Description

Clears failed login state for all master traders.

Success Response

{
  "success": true,
  "message": "All failed traders cleared successfully.",
  "failed_before_clear": 4
}

=================

# 📌 RULES FOR MASTER + SLAVE

=================

1. Email Must Be Unique

A master and a slave cannot share the same email.

2. MT5 Account Number Must Be Unique

Checked using account_no_exists().

3. Updating MT5 Login Clears These Fields

all_symbol
trade_symbol
login_status
account_name
balance
equity
today_profit
weekly_profit
monthly_profit
currency
broker_time_zone
mt5_version
mt5_terminal_info
mt5_account_info

4. All Dates Are Strings in YYYY-MM-DD Format
